111.12 Pressure gauge 0…100 bar, Ø63 mm, G 1/4"

111.12 Pressure gauge 0…100 bar, Ø63 mm, G 1/4"

WIKA
PG-100-63-H-D

Dry pressure gauge

Measuring range: 0…100 bar

Case diameter: Ø63 mm

Connection: G 1/4" horizontal

Accuracy class: 2.5

Manufacturer / model: WIKA 111.12

Code: 9084002

Out of Stock


Terms of use



Delivery Terms

WIKA 111.12 series pressure gauges are mechanical general-purpose instruments designed for pressure monitoring in systems using non-aggressive gases or liquids.

The plastic case and brass measuring system provide a practical solution for standard operating conditions. The simple and proven construction makes the 111.12 series suitable for hydraulic and pneumatic systems, compressors, pumps, water supply installations and pressure control equipment.

The series is available in multiple configurations to match different application requirements.

: PG-100-63-H-D
Out of Stock

Data sheet

Diameter
63 mm
Measurement range
0…100 bar
Filling
Dry (no filling)
Thread
G 1/4"
Connection orientation
Horizontal (back connection)
Working Pressure
100 bar
Accuracy class
2.5
Min temperature
–20 °C
Max temperature
+60 °C
Case material
Plastic
Measuring system
Brass
Protection class
IP42
Standard
EN 837-1
WIKA series
111.12
Brand
WIKA

Specific References

MPN
9084002
