Vacuum gauge −1…15 bar, Ø80 mm, G 1/2"

Vacuum gauge −1…15 bar, Ø80 mm, G 1/2"

WIKA
PGV-1-15-80-V-D

Dry vacuum gauge for vacuum measurement.

Measuring range: −1…15 bar

Case diameter: Ø80 mm

Connection: G 1/2" vertical

Accuracy class: 2.5

Manufacturer / model: WIKA 111.10

Code: 9020284

Out of Stock


Terms of use



Delivery Terms

Vacuum gauges are designed for monitoring negative pressure in industrial and technical systems. They provide clear indication of vacuum level and help ensure stable operation of equipment.

These instruments are widely used in vacuum systems, pumps, filtration units, packaging lines, laboratory and process equipment where continuous vacuum monitoring is required. The mechanical design ensures simple and reliable operation under standard service conditions.

Vacuum gauges are available in various pressure ranges, case sizes and connection types to suit different technical requirements.

: PGV-1-15-80-V-D
Out of Stock

Data sheet

Diameter
80 mm
Measurement range
-1…15 bar
Filling
Dry (no filling)
Thread
G 1/2"
Connection orientation
Vertical (bottom connection)
Vacuum
-1 bar
Working Pressure
15 bar
Accuracy class
2.5
Min temperature
–20 °C
Max temperature
+60 °C
Case material
Plastic
Measuring system
Brass
Protection class
IP42
Standard
EN 837-1
WIKA series
111.10
Brand
WIKA

Specific References

MPN
9020284
